PLUS+1 displays

PLUS+1 displays Specification

Connectivity Type
CAN bus, USB

Current
500 mA (max)

Installation Type
Panel-mounted

Protection Level
High vibration and shock resistance

Usage & Applications
Operator interfaces, machine controls

Display
Sunlight-readable, Color LCD

Switch Type
Touchscreen and push-button compatible

Mounting Type
Panel mount

Output
CAN and I/O

Features
Sunlight readability, programmable, robust design

Sensor Type
Compatible with multiple sensor types

Frequency
50 Hertz (HZ)

IP Rating
IP67

Measuring Range
Customizable

Product Type
PLUS+1 displays

Operating Temperature
-30C to +70C

Working Temperature
-30C to +70C

Input
Analog & Digital Inputs

Application
Industrial

Supply Voltage
12/24 V DC

Accuracy
100 %

Dimension (L*W*H)
See model specific datasheet

Weight
Varies by model

Warranty
1 Year

Resolution
QVGA to SVGA (model dependent)

Processor
High performance embedded processor

Touch Capability
Optional, model-specific

Connector Type
Sealed automotive connectors

Software Support
PLUS+1 GUIDE software suite

Backlight
LED, adjustable brightness

Memory
Flash and RAM (size varies by model)

Screen Size
Typically 3.5" to 12.1" (model dependent)

Operating Humidity
0% to 95% non-condensing

Operating System
PLUS+1 Guide programmable

Update Method
USB and CAN firmware update

PLUS+1 displays Trade Information

Minimum Order Quantity
10 Units

Supply Ability
5000 Units Per Month

Delivery Time
10 Days

About PLUS+1 displays

Our range of strong and durable PLUS+1(R) programmable displays is made to function reliably in a range of situations, both inside and outside the vehicle. They have bright, high-quality screens, come in a variety of sizes, and have a number of customisable features.

Diagnostics, control, and monitoring

It has never been simpler to keep an eye on a car's performance. Our screens provide a personalised, comprehensive overview of the CAN-based network in your car. Exactly what operators require for ongoing diagnostics, control, and monitoring.

Our PLUS+1® programmable displays offer a wide range of possibilities, from plug and play to customised operator interfaces with an optional external camera.

One feature unites all of our displays: they offer an integrated operating network that connects your car's hydraulic system as a whole. Our displays are capable of tracking every hydraulically controlled detail, including machine angles and oil pressure, regardless of your needs.

Seamless Integration and Programmability

PLUS+1 displays can be fully tailored using the PLUS+1 GUIDE software suite. This programming environment enables precise configuration for both analog and digital I/O, making each display adaptable to specialized industrial applications. Users benefit from simplified system updates and maintenance, thanks to streamlined USB and CAN-based firmware update processes.

Durability in Harsh Environments

Designed with ruggedness in mind, these operator interfaces thrive under extreme conditions. The IP67-rated enclosures protect against dust and water, while high resistance to vibration and shock ensures reliability on heavy-duty equipment. Displays maintain optimal performance in a broad temperature range, from -30C to +70C, suitable for both indoor and outdoor machinery.

User-Friendly and Versatile Operation

The displays offer a choice of touchscreen and push-button interfaces, allowing flexible operation. Engineered for operator comfort, the sunlight-readable, high-resolution color screens enable clear visibility even in direct sunlight. Optional touch capability on select models enhances interactive control, meeting diverse usability requirements.

FAQ's of PLUS+1 displays:

Q: How do I update the firmware on a PLUS+1 display?

A: Firmware can be updated using either the USB or CAN interfaces. Use the PLUS+1 GUIDE software suite to manage and execute updates, following the procedures detailed in your model's user manual for a seamless process.

Q: What are the key applications of PLUS+1 displays?

A: These displays are widely used as operator interfaces and machine controls across various industrial sectors. Their programmable nature and robust design make them suitable for heavy machinery, vehicles, and other demanding environments requiring reliable performance.

Q: When should I use a display with touchscreen capability?

A: Touchscreen models are ideal when interactive control is desired, offering intuitive operation for functions such as navigation, data entry, and quick adjustments. Selection depends on your application's specific needs and the compatible models available.

Q: Where are PLUS+1 displays typically installed?

A: PLUS+1 displays are designed for panel mounting in operator cabins, control panels, or dashboards of industrial machinery. Their sealed connectors and IP67 rating make them suitable for both indoor and outdoor installation.

Q: What is the benefit of adjustable brightness with LED backlighting?

A: Adjustable brightness improves visibility in varying lighting conditions, from direct sunlight to low-light environments. This feature ensures clear screen readability and reduces eye strain for operators working long hours.

Q: What process should I follow to customize display inputs and outputs?

A: Customization is managed via the PLUS+1 GUIDE software suite. Configure analog and digital inputs/outputs, sensor compatibility, and display parameters based on your operation requirements within the programming environment provided.
