PVG 16 proportional valves

Get a Price/Quote

Product Details:

Application Mobile machinery, Construction equipment, Agricultural machinery
Mounting Type Subplate or direct mount
Sealing NBR (Buna-N) or FKM (Viton)
Voltage 12V DC / 24V DC
Capacity Sectional - multiple modules per assembly
Valve Type Proportional directional control valve
Connection Flanged/Threaded
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

PVG 16 proportional valves Price And Quantity

Minimum Order Quantity 1 Piece

Spool Function Available with standard, float, regenerative, and special spools
Hydraulic Connections A, B, P, T: BSP, NPT or SAE ports available
Weight Approximately 7.5 kg (per section)
Response Time < 50 ms
Feedback Optional position feedback via sensor
Environmental Suitable for outdoor and severe environments
Compatible Fluids Mineral oils to ISO 6743/4, other fluids on request
Coil Insulation Class Class F
Control Manual lever, electric proportional, or remote control via CAN bus
Protection Overpressure and anti-cavitation valves optional

PVG 16 proportional valves Product Specifications

Pressure Ratings Up to 420 bar (max)
Application Mobile machinery, Construction equipment, Agricultural machinery
Connection Flanged/Threaded
Material High-strength cast iron body, hardened steel components
Structure Sectional type proportional directional control valve
Model PVG 16
Pipe Connection Type Threaded or Flanged
Media Hydraulic Oil
IP Rating IP65
Sealing NBR (Buna-N) or FKM (Viton)
Flow Rate Up to 180 L/min
Mounting Type Subplate or direct mount
Diameter 16 mm spool diameter
Power Electrohydraulic, 12V or 24V coil options
Noise Level Less than 70 dB(A)
Valve Type Proportional directional control valve
Temperature -20C to +80C
Port Size 1/2 BSPP or SAE
Capacity Sectional - multiple modules per assembly
Voltage 12V DC / 24V DC
Standard ISO 4401 / CETOP RP 121H

Spool Function Available with standard, float, regenerative, and special spools
Hydraulic Connections A, B, P, T: BSP, NPT or SAE ports available
Weight Approximately 7.5 kg (per section)
Response Time < 50 ms
Feedback Optional position feedback via sensor
Environmental Suitable for outdoor and severe environments
Compatible Fluids Mineral oils to ISO 6743/4, other fluids on request
Coil Insulation Class Class F
Control Manual lever, electric proportional, or remote control via CAN bus
Protection Overpressure and anti-cavitation valves optional

Product Description

Introducing the new release PVG 16 Proportional Valve-your cost-effective solution for high-performance fluid control. Designed for mobile and construction equipment, this valve offers a dazzling array of spool functions, lightning-fast response time (<50 ms), and an impressive flow rate up to 180 L/min. With monumental versatility including manual, electric, and CAN bus controls, and best-in-class durability from its cast iron body, the PVG 16 ensures unmatched reliability. Secure this limited-time offer and benefit from advanced safety, IP65 protection, and seamless compatibility with ISO 4401 standards.

Enhance Applications with PVG 16's Extra Features

The PVG 16 proportional valve stands out with its optional position feedback, robust anti-cavitation and overpressure protections, and modular sectional design. Its ability to handle various spool functions-float, regenerative, and more-makes it perfect for demanding machinery environments. Used widely in mobile, construction, and agricultural equipment, PVG 16's primary advantages lie in its superior response time, adaptable connections, and resilient build, positioning it ahead of competitors for long-term, reliable performance.

Export, Delivery, and Packaging Details for PVG 16

Available FOB major Indian ports, PVG 16 valves are packaged securely to prevent transit damage and maintain product integrity. Samples can be provided; charges depend on specific requirements and destination. Our main export markets include Asia, Europe, and the Middle East, with efficient delivery processes ensuring products reach you promptly. Rely on us for professional export documentation and streamlined logistics, tailored to meet your business needs every time.

FAQ's of PVG 16 proportional valves:

Q: How can I control the PVG 16 proportional valves?

A: The PVG 16 can be controlled using a manual lever, electric proportional actuator, or remotely via CAN bus, offering versatile integration into various systems.

Q: What are the main benefits of using PVG 16 valves in mobile machinery?

A: PVG 16 valves provide fast response times, reliable performance in severe outdoor environments, and compatibility with multiple control methods, making them ideal for mobile and heavy-duty equipment.

Q: Where can PVG 16 valves be installed?

A: These valves are suitable for installation on mobile, construction, and agricultural machinery, and can be mounted using subplate or direct mounting methods based on application requirements.

Q: What spool functions are available with the PVG 16?

A: The PVG 16 supports standard, float, regenerative, and special spool configurations, allowing for tailored hydraulic functionality in a range of systems.

Q: How does the PVG 16 valve ensure operational safety?

A: Operational safety is enhanced with optional overpressure and anti-cavitation valves, robust NBR or FKM sealing, and construction meeting IP65 environmental standards.
