Solenoid valves

Solenoid valves Specification

Usage
Industrial

Color
Black

Solenoid valves Trade Information

Minimum Order Quantity
10 Units

Supply Ability
5000 Units Per Month

Delivery Time
10 Days

About Solenoid valves

Features and benefits

Flow rating up to 230 l/min [60 US gal/min]
Pressure rating up to 350 bar [5000 psi]

Poppet type solenoid valves

Product Code	Cavity	Flow	Pressure
SVP08-NC	SDC08-2	35 l/min [9 US gpm]	230 bar [3300 psi]
SV15-8-C	SDC08-2	38 l/min [10 US gpm]	350 bar [5000 psi]
SVP10-NC	SDC10-2	80 l/min [21 US gpm]	230 bar [3300 psi]
SV11-10-C	SDC10-2	45 l/min [12 US gpm]	350 bar [5000 psi]
SVP08-NCF	SDC08-2	15 l/min [4 US gpm]	230 bar [3300 psi]
SVP08-NCR	SDC08-2	35 l/min [9 US gpm]	230 bar [3300 psi]
SVP10-NCR	SDC10-2	80 l/min [21 US gpm]	230 bar [3300 psi]
SV13-10-C	SDC10-2	45 l/min [12 US gpm]	350 bar [5000 psi]
SV3-12-C	C-12-2	114 l/min [30 US gpm]	210 bar [3000 psi]
SV13-12-C	C-12-2	114 l/min [30 US gpm]	350 bar [5000 psi]
SV1-16-C	SDC16-2	132 l/min [35 US gpm]	210 bar [3000 psi]
SV13-16-C	SDC16-2	132 l/min [35 US gpm]	350 bar [5000 psi]
SV2-20-C	SDC20-2	230 l/min [60 US gpm]	210 bar [3000 psi]
SV13-20-C	SDC20-2	230 l/min [60 US gpm]	350 bar [5000 psi]
SBV12-8-C	SDC08-2	1 l/min [0.25 US gpm]	350 bar [5000 psi]
SVP08-CDB	SDC08-2	25 l/min [6.6 US gpm]	230 bar [3300 psi]
EVK 06/C5	NCS06/2	40 l/min [10.6 US gpm]	210 bar [3000 psi]
SBV11-8-C	SDC08-2	60 l/min [16 US gpm]	350 bar [5000 psi]
SBV1-10-C	SDC10-2	76 l/min [20 US gpm]	210 bar [3000 psi]
SBV11-10-C	SDC10-2	76 l/min [20 US gpm]	350 bar [5000 psi]
SBV1-12-C	C-12-2	114 l/min [30 US gpm]	210 bar [3000 psi]
SBV11-12-C	C-12-2	114 l/min [30 US gpm]	350 bar [5000 psi]
SVP08-NO	SDC08-2	35 l/min [9 US gpm]	230 bar [3300 psi]
SV15-8-O	SDC08-2	38 l/min [10 US gpm]	350 bar [5000 psi]
SVP10-NO	SDC10-2	80 l/min [21 US gpm]	230 bar [3300 psi]
SV15-10-O	SDC10-2	45 l/min [12 US gpm]	350 bar [5000 psi]
SVP08-NOR	SDC08-2	35 l/min [9 US gpm]	230 bar [3300 psi]
SVP10-NOR	SDC10-2	80 l/min [21 US gpm]	230 bar [3300 psi]
SV13-10-O	SDC10-2	45 l/min [12 US gpm]	350 bar [5000 psi]
SV3-12-O	C-12-2	114 l/min [30 US gpm]	210 bar [3000 psi]
SV13-12-O	C-12-2	114 l/min [30 US gpm]	350 bar [5000 psi]
SV3-16-O	SDC16-2	132 l/min [35 US gpm]	210 bar [3000 psi]
SV13-16-O	SDC16-2	132 l/min [35 US gpm]	350 bar [5000 psi]
SV3-20-O	SDC20-2	230 l/min [60 US gpm]	210 bar [3000 psi]
SV13-20-O	SDC20-2	230 l/min [60 US gpm]	350 bar [5000 psi]
S207	A879	1 l/min [0.25 US gpm]	350 bar [5000 psi]
SBV11-8-O	SDC08-2	60 l/min [16 US gpm]	350 bar [5000 psi]
SBV11-10-O	SDC10-2	76 l/min [20 US gpm]	350 bar [5000 psi]
SBV11-12-O	C-12-2	114 l/min [30 US gpm]	350 bar [5000 psi]
EVH 06/D5	NCS06/3	25 l/min [6.6 US gpm]	230 bar [3300 psi]

Spool type 2-way, 2-position solenoid valves

Product Code	Cavity	Flow	Pressure
SV08-22-02	SDC08-2	18 l/min [4.7 US gpm]	230 bar [3300 psi]
HSV08-22-02	SDC08-2	20 l/min [5.3 US gpm]	350 bar [5000 psi]
SV10-22-02	SDC10-2	35 l/min [9 US gpm]	230 bar [3300 psi]
SV14-10-C	SDC10-2	23 l/min [6 US gpm]	350 bar [5000 psi]
SV15-22-02	NCS12/2	60 l/min [16 US gpm]	230 bar [3300 psi]
SV08-22-01	SDC08-2	16 l/min [4.2 US gpm]	230 bar [3300 psi]
HSV08-22-01	SDC08-2	20 l/min [5.3 US gpm]	350 bar [5000 psi]
SV10-22-01	SDC10-2	35 l/min [9 US gpm]	230 bar [3300 psi]
SV14-10-O	SDC10-2	23 l/min [6 US gpm]	350 bar [5000 psi]
SV15-22-01	NCS12/2	60 l/min [16 US gpm]	230 bar [3300 psi]

Spool type 3-way, 2-position solenoid valves

Product Code	Cavity	Flow	Pressure
SV08-23-01	SDC08-3	18 l/min [4.8 US gpm]	230 bar [3300 psi]
SV10-23-01	SDC10-3	35 l/min [9.2 US gpm]	230 bar [3300 psi]
HSV08-23-01	SDC08-3	15 l/min [4 US gpm]	350 bar [5000 psi]
CP521-21	CP12-3	60 l/min [16 US gpm]	240 bar [3500 psi]
SV11M-12-3P	C-12-3	35 l/min [9 US gpm]	350 bar [5000 psi]
SV08-23-02	SDC08-3	18 l/min [4.8 US gpm]	230 bar [3300 psi]
HSV08-23-02	SDC08-3	15 l/min [4 US gpm]	350 bar [5000 psi]
SV09-23-02	SDC10-3	21 l/min [5.5 US gpm]	100 bar [1450 psi]
SV10-23-02	SDC10-3	28 l/min [7.4 US gpm]	230 bar [3300 psi]
SV11-10-3	SDC10-3	23 l/min [6 US gpm]	350 bar [5000 psi]
SV08-23-03	SDC08-3	18 l/min [4.7 US gpm]	230 bar [3300 psi]
SV10-23-03	SDC10-3	28 l/min [7.4 US gpm]	230 bar [3300 psi]
SV4M-12-3P	C-12-3	42 l/min [11 US gpm]	210 bar [3000 psi]
SV08-23-04	SDC08-3	12 l/min [3.2 US gpm]	230 bar [3300 psi]
SV10-23-04	SDC10-3	20 l/min [5.3 US gpm]	230 bar [3300 psi]
SV15-23-04	NCS12/3	50 l/min [13.2 US gpm]	230 bar [3300 psi]

Spool type 4-way, 2-position solenoid valves

Product Code	Cavity	Flow	Pressure
SV08-24-01	SDC08-4	12 l/min [3.2 US gpm]	230 bar [3300 psi]
HSV08-24-01	SDC08-4	20 l/min [5.3 US gpm]	350 bar [5000 psi]
SV09-24-01	SDC10-4	21 l/min [5.5 US gpm]	100 bar [1450 psi]
SV10-24-01	SDC10-4	35 l/min [9 US gpm]	230 bar [3300 psi]
SV11-10-4	SDC10-4	23 l/min [6 US gpm]	350 bar [5000 psi]
SV15-24-01	NCS12/4	60 l/min [16 US gpm]	230 bar [3300 psi]
SV08-24-02	SDC08-4	12 l/min [3.2 US gpm]	230 bar [3300 psi]
SV12-8-4	SDC08-4	11 l/min [2.9 US gpm]	350 bar [5000 psi]
SV10-24-02	SDC10-4	25 l/min [6.6 US gpm]	230 bar [3300 psi]
SV12-10-4	SDC10-4	23 l/min [6 US gpm]	350 bar [5000 psi]
SV15-24-02	NCS12/4	60 l/min [16 US gpm]	230 bar [3300 psi]
SV15-24-03	NCS12/4	50 l/min [13.2 US gpm]	230 bar [3300 psi]
SV08-24-04	SDC08-4	8 l/min [2 US gpm]	230 bar [3300 psi]
SV15-24-04	NCS12/4	50 l/min [13.2 US gpm]	230 bar [3300 psi]
SV10-24-05	SDC10-4	30 l/min [8 US gpm]	230 bar [3300 psi]
SV10-24-06	SDC10-4	30 l/min [8 US gpm]	230 bar [3300 psi]
SV10-24-07	SDC10-4	30 l/min [8 US gpm]	230 bar [3300 psi]
SV08-24-08	SDC08-4	18 l/min [4.7 US gpm]	230 bar [3300 psi]
SV10-24-12	SDC10-4	25 l/min [6.6 US gpm]	230 bar [3300 psi]
SV10-24-13	SDC10-4	33 l/min [8.7 US gpm]	230 bar [3300 psi]
SV7M-12-4P	C-12-4	38 l/min [10 US gpm]	210 bar [3000 psi]
SV17M-12-4P	C-12-4	38 l/min [10 US gpm]	350 bar [5000 psi]

Spool type 4-way, 3-position solenoid valves

Product Code	Cavity	Flow	Pressure
SV08-34-02	SDC08-4	16 l/min [4.2 US gpm]	230 bar [3300 psi]
HSV08-34-02	SDC08-4	17 l/min [4.5 US gpm]	350 bar [5000 psi]
SV10-34-02	SDC10-4	25 l/min [6.6 US gpm]	230 bar [3300 psi]
SV15-34-02	NCS12/4	60 l/min [16 US gpm]	230 bar [3300 psi]
SV08-34-03	SDC08-4	8 l/min [2 US gpm]	230 bar [3300 psi]
SV10-34-03	SDC10-4	24 l/min [6.3 US gpm]	230 bar [3300 psi]
SV15-34-03	NCS12/4	50 l/min [13.2 US gpm]	230 bar [3300 psi]
SV08-34-04	SDC08-4	8 l/min [2 US gpm]	230 bar [3300 psi]
SV10-34-04	SDC10-4	24 l/min [6.3 US gpm]	230 bar [3300 psi]
SV15-34-04	NCS12/4	50 l/min [13.2 US gpm]	230 bar [3300 psi]
SV08-34-05	SDC08-4	12 l/min [3.2 US gpm]	230 bar [3300 psi]
HSV08-34-05	SDC08-4	17 l/min [4.5 US gpm]	350 bar [5000 psi]
SV10-34-05	SDC10-4	24 l/min [6.3 US gpm]	230 bar [3300 psi]
SV15-34-05	NCS12/4	60 l/min [16 US gpm]	230 bar [3300 psi]
SV10-34-11	SDC10-4	28 l/min [7.4 US gpm]	230 bar [3300 psi]

Spool type 5-way, 3-position solenoid valves

Product Code	Cavity	Flow	Pressure
SV10-35-02	SDC10-5	30 l/min [8 US gpm]	230 bar [3300 psi]
SV10-35-05	SDC10-5	30 l/min [8 US gpm]	230 bar [3300 psi]

Premium Alloy Construction

Crafted from resilient alloy material, our solenoid valves stand up to heavy-duty industrial usage. The robust metal ensures superior longevity and corrosion resistance, ensuring uninterrupted performance even under harsh conditions.

Reliable Industrial Performance

These solenoid valves are optimized for industrial environments, with standard sizing for straightforward replacement and integration. The hydraulic power mechanism guarantees reliable actuation suitable for a wide range of automation and fluid control needs.

FAQ's of Solenoid valves:

Q: How do these black solenoid valves operate in industrial settings?

A: Our solenoid valves utilize hydraulic power to control the flow of liquids in industrial systems. They function by using electrical signals to convert hydraulic power, enabling precise and automatic flow control in various machinery applications.

Q: What are the main benefits of using alloy solenoid valves for industrial use?

A: Alloy provides higher strength, resistance to corrosion, and reliable durability, making our valves suitable for demanding industrial environments. This ensures longer operational life and reduced maintenance requirements.

Q: When should I choose a standard-size hydraulic solenoid valve for my facility?

A: Standard-size solenoid valves are typically chosen when compatibility with existing industrial systems is required. They are ideal for facilities looking to simplify installation or replacement without custom fittings.

Q: Where can these solenoid valves be sourced in India?

A: We are a recognized supplier and trader across India. You can source these valves by contacting our distribution channels or visiting our authorized dealership networks nationwide.

Q: What is the process for installing these solenoid valves in hydraulic systems?

A: Installation involves positioning the valve in the designed hydraulic line, ensuring proper alignment with flow direction, securing with suitable fittings, and connecting to the control circuit. Professional plumbers or technicians should always be engaged for secure and compliant installation.

Q: How should these solenoid valves be maintained for optimal performance?

A: Regular inspection for debris, periodic cleaning, and ensuring hydraulic connections are leak-free help maintain valve efficiency. Scheduled servicing, as per manufacturer guidelines, also extends product life and reliability.
